Long Overhead Fixed Incline Belt Conveyor with High Safety System and Low Price for Material Handling Equipment, Cement, Mining and Construction Machinery

Long Overhead Fixed Incline Belt Conveyor with High Safety System and Low Price for Material Handling Equipment, Cement, Mining and Construction Machinery

PRODUCT INTRODUCTION PRODUCT OVERVIEW Fixed belt conveyor is a general series of products, a continuous convey device wi
Basic Info.
Model NO. Fixed Belt Conveyor
Condition New
Drive Drum Diameter D500-1400mm
Roller Diameter 0.89~1.159 mm
Multi-Machine Power 22~630kw
Type Customizable Belt Conveyor
Others Design Scheme According to Parameters
Tension Mode Spiral, Weight, Winch, Automatic Tension, etc.
Capacity 69~4130 M3/ H
Single Machine Power 1.1~630kw,
Inclination Angle up-Haul 0~25°; Down-Haul 0~20°
Belt Speed 0.8~5.0m/S
Belt Width B500~1400mm
Transport Package Land-Carriage, Ocean Shipping, etc.
Specification Drive drum diameter: D500-1400mm
Trademark OEM
Origin China
Product Description

PRODUCT INTRODUCTION
PRODUCT OVERVIEW
Fixed belt conveyor is a general series of products, a continuous convey device with cotton canvas, nylon, polyester canvas and wire rope core conveyor belt as traction components. It is suitable for conveying bulk materials and finished goods, with packing density of 500 ~ 2500 kg/ m3 at ambient temperature of -25 ~ + 40ºC.
The fixed belt conveyor is designed according to the series of parts. The whole machine can be assembled according to the process route, design and calculation in accordance with different terrain and working conditions. It can meet the conditions of horizontal, upper and lower transportation. And it can also adopt the transportation form with combination of convex arc section, concave arc segment and straight-line segment. Conveyors should be installed in the corridor as far as possible, in the open environment, and the driving part should be provided with protective cover. For places with special requirements, the corresponding protective measures should be taken, such as high temperature, cold, explosion-proof, flame retardant, anti-corrosion, acid and alkali resistance, waterproof, etc..
PERFORMANCE CHARACTERISTICS
1. A wide range of materials to be transported 2. Wide range of conveying capacity 3. Adaptability of transmission lines 4. Flexible handling of materials 5. Strong reliability 6. High safety 7. Low costs
TECHNICAL PARAMETER
1. Bandwidth: B500~1400mm band speed: 0.8~5.0m/s capacity: 69~4130 m3/ h inclination angle: Up-haul 0~25°, down-haul 0~20 °.2. Power: Single machine 1.1~630kW, multi-machine 22~630KW drive drum diameter: D500~1400mm roller diameter: 0.89~1.159 mm.3. Tension mode: Spiral, weight, winch, hydraulic automatic tension, etc..
No.SpecificationsConveyingCapacity (t/h)Belt Speed(m/s)Belt Width(mm)Main MachinePowerDrive DrumDiameter (mm)Roller Diameter (mm)
1DTL80/40/75400280075500108
2DTL80/40/2*9040028002*90500108
3DTL100/45/2*754502.510002*75630108
4DTL100/63/2*1326302.510002*132630108
5DTL120/180/318003.512003*250830133
6DTL140/200/2*4002000414002*4001000159
7DTL160/400/3*10040004.516003*10001600194
8DTL180/450/3*6304500518003*6301400194
9DTL200/500/35000520003*6301600194


Long Overhead Fixed Incline Belt Conveyor with High Safety System and Low Price for Material Handling Equipment, Cement, Mining and Construction Machinery


Long Overhead Fixed Incline Belt Conveyor with High Safety System and Low Price for Material Handling Equipment, Cement, Mining and Construction Machinery



COMPANY PROFILE
ABOUT US
Shanxi Huaxin Electric Co., Ltd. is located in Yangquan, the largest anthracite base in China. Founded in May 2003, the company's registered capital was RMB 114 million, with total assets of RMB 815 million and the existing staff of over 1100. At present, our company has six industrial parks, divided into Changling Industrial Park, Four Mining Industrial Park, Lock Spring Industrial Park, Taiyuan Industrial Park, Jinnan Remanufacturing Park, and Jindong Remanufacturing Park, covering a total area of over 650 acres.

Our company has more than 30 patents now, mainly engaged in the R&D and production of intelligent electric automation, intelligent transportation and lifting, intelligent warehousing, power system, ventilation fluid and other series of over 80 products.Our company has registered five R&D institutions in Beijing, Shenyang, Shanghai and Taiyuan, laying a solid foundation for technical upgrading and renewing generation for products. And it has been responsible for the production of the high-efficiency, energy-saving core technology products required by the national Eleventh Five-year plan, and the research and development of the high-efficiency permanent magnet motor and frequency conversion control, the key projects of national energy-saving for the Twelfth Five-year plan.
CERTIFICATIONS


AWARDS
1.High-tech Enterprise, Provincial Technology Center2.Two-phase Fusion Demonstration Enterprises3.China Quality and Integrity Enterprise4.Shanxi Top 100 Enterprises5.Shanxi Top 100 Manufacturing Enterprises6.Following Contract and Observing Credit Enterprise7.Shanxi Quality and Reputation AAA-Class Enterprise8.Small and Medium-sized Enterprises of Science and Technology9.Technology Center of Shanxi Small and Medium-sized Enterprises10.ISO9001 Quality Management System11.ISO14001 Environmental Management System12.ISO18001 Occupational Health and Safety Management System13.National Torch Program14.Golden Bridge Award of China Technical Market15.Measurement Guarantee Unit
ACHIEVEMENTS
1.The first production enterprise in rare earth flameproof permanent magnet motor and flameproof flat coil core transformer for mining.2.One of the country's three major mining transformation production bases, and the largest coal machine equipment manufacturing enterprise in Shanxi province.3.The permanent magnet direct drive motor and frequency conversion control produced by our company, have put into use in Zhengzhou Coal Industry Group, Shanxi Coal and Chemical Industry Group, Yangquan Coal Industry Group and other major coal industry groups.4.Distribution transformer products have been successfully shortlisted as qualified suppliers for National Power Grid and China Southern Power Grid.
ATTENTION
1. The payment term: We accept TT, 30% deposit and 70% balance against copy of BL.2. The delivery time: Usually it will take about 3 months.3. The standard of package: Usually use strong plywood case for protection.4. Warranty: In 12 months since BL date.
SERVICE
1. Reply within 24 hours.2. Perfect service commitment.3. Provide services during the pre-sales, in-sales and after-sales, all the way (Including quality warranty).4. Be free of charge in training and tutoring after sales.
